In this video, we show you how to change the AV Spring on a Husqvarna K760.

Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.

Transcript

Today, we're going to change the anti-vibration spring on a Husqvarna K760 Disc Cutter. First of all, use a torx spanner to remove the screws on the air filter cover. Next, remove the orange base holding the air filter by loosening with a torx spanner. Then, unscrew the four torx screws to remove the grey air filter housing. You will now have access to the anti-vibration spring. Use a torx spanner to remove the bolt securing the AV spring. You will then need the Husqvarna torx spanner which has a slimmer shaft to reach through the middle of the spring. Then, place your new anti-vibration spring in position and tighten with the Husqvarna torx spanner. Add in the second screw and tighten with a torx spanner. Place the air filter housing back on and screw in using a torx spanner. Pull the bellow back through the housing. Place the base and the air filter back in place and screw in using a torx spanner. Put the air filter cover back into position and tighten the screws with a torx spanner. Be careful not to tighten too much into the plastic. That's how you change the anti-vibration spring on a Husqvarna K760 Disc Cutter.

Parts

Parts and tools included in the K760 how-to video.

• Spring Damper - 522 47 57 01
• Compression Spring - 506 26 68 01
• Screw - 503 21 53 40
• Combination Tool - 506 38 26 01
