How to Change the Clutch using a Bearing Puller on a Belle PCLX 320 Plate Compactor
In this video, we show you how to replace the clutch on a Belle PCLX 320 Plate Compactor.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today we're going to change the clutch on a Belle PCLX 320 Plate Compactor. Firstly, remove the cover by unscrewing the 4 bolts and washers using a 10mm socket. Then, remove the belt from the clutch safely. Now, remove the screw with a ratchet, releasing the spring washer and the larger washer. Get your bearing puller and place it around the clutch. Tighten slightly so the bearing puller is in place. Using a ratchet and the appropriate sockets, slowly tighten the bearing puller until it releases the clutch off. Get your new clutch and place it back into position. Return the washers back and tighten with the screw. Position the belt back and secure. Tighten with a 13mm socket. Reattach the cover back and secure with the washers and 4 bolts. That's how you change the clutch on a Belle PCLX 320 Plate Compactor.
Parts
Parts and tools included in the Belle PCLX 320 how-to video.
- Clutch - 21/0161
- Bahco S240 Socket Set of 24 Metric 1/2in Drive - 902 0092
- Bearing Puller 75, 150 & 200mm - FAIBEARPULL4
- Copper Hammers - Copper Hammer
