How to Change the Magazine and Brad on a Paslode IM65 Nail Gun

Lauren Published on Jun 15, 2022 View Comments

In this video, we show you how to Replace a Magazine and Brad on a Paslode IM65 Nail Gun.

Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.

Transcript

Today we're going to replace the Magazine and Brad on a Paslode IM65 Nailer. Remove the two screws from either side of the cap. Remove the 4 shoulder screws using the provided allen key. You can now remove the cap. Disconnect the spark and fan wires. Take off the cylinder head by twisting. Disconnect the retaining ring by removing the screw with the provided allen key. Remove the 2 screws, then the 4 holding the body together. Remove the front channel. Now you can lift the combustion chamber and magazine out from the body of the nailer. To remove the nose from the sleeve, disconnect the two screws using the provided allen key. The dowel pin may fall out easily, if not remove the front plate assembly by pushing out the dowel pin. Then remove the lockout bar, pin and spring To remove the nose from the magazine you will need to disconnect the two screws. Then you can remove and check the brad channel. Now you have access to the magazine. Place the brad channel back into position. Place the nose back onto the magazine and connect with the two screws. Reattach the lockout bar, pin and spring. Place the nose back on to the sleeve and connect with the dowel pin. Secure with the two screws Return the combustion chamber and magazine back into the right handle body. Then clip the left handle body into the magazine and make sure the body of the nailer shuts firmly. Secure the two shoulder screws and then four screws holding the body together. Fix the front channel back. Return the retaining ring and fix it in place with the screw. Secure the cylinder head. Connect the wires back into position Place the cap back until flush. Secure with the 6 screws. That's how you replace the Magazine and Brad on a Paslode IM65 Nailer.

Parts

Parts and tools included in the Paslode IM65 Nail Gun how-to video.
