How to Change the Pulley using a Bearing Puller on a Belle PCLX 320 Plate Compactor
In this video, we show you how to replace the clutch on a Belle PCLX 320 Plate Compactor.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today we're going to change the pulley on a Belle PCLX 320 Plate Compactor. Firstly, remove the cover by unscrewing the 4 bolts and washers using a 10mm socket and ratchet. Then, remove the belt from the pulley and the clutch safely. Get your bearing puller and place it around the pulley. Tighten slightly so the bearing puller is in place. Using a 9mm socket, connect this to the front of the bearing puller. Then with a 16mm socket and ratchet, slowly release the clutch off. Get your new clutch and tap this back on carefully with a copper hammer. Return the washer and bolt back over the pulley. Tighten with a 13mm socket and ratchet. Place the belt back and secure. Reattach the cover back and secure with the 4 washers and bolts. That's how you change the pulley on a Belle PCLX 320 Plate Compactor.
Parts
Parts and tools included in the Belle PCLX 320 how-to video.
- Pulley - 151.0.221
- Bahco S240 Socket Set of 24 Metric 1/2in Drive - 902 0092
- Bearing Puller 75, 150 & 200mm - FAIBEARPULL4
- Copper Hammers - Copper Hammer
