How to Change the Yoke, Knob and Spring Guide on a Paslode IM65 Nail Gun
In this video, we show you how to Change the Yoke, Knob and Spring Guide on a Paslode IM65 Nail Gun.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today we're going to replace the yoke, Knob and Spring Guide on a Paslode IM65 Nailer. Remove the two screws from either side of the cap. Remove the 4 shoulder screws using the provided allen key. You can now remove the cap. Disconnect the spark and fan wires. Then remove the cylinder head by twisting. Disconnect the retaining ring by removing the screw with the provided allen key. Remove the 2 screws, then the 4 holding the body together. Remove the front channel. Now you can lift the combustion chamber and magazine out from the body of the nailer. Loosen the 2 screws by using a star drive to remove the yoke. Now you will have access to the springs. These may fall out very easily. Disconnect the probe by unscrewing Reconnect the probe. With the new springs slide these back onto the new yoke, with the probe bumpers sliding into the clips. Place the yoke back on to the combustion chamber and tighten with the 2 screws. Return the combustion chamber and magazine back into the right handle body. Then clip the left handle body into the magazine and make sure the body of the nailer shuts firmly. Secure the two shoulder screws and then four screws holding the body together. Fix the front channel back. Return the retaining ring and fix it in place with the screw. Secure the cylinder head. Connect the wires back into position Place the cap back until flush. Secure with the 6 screws. That's how you replace the yoke, Knob and Spring Guide on a Paslode IM65 Nailer.
Parts
Parts and tools included in the Paslode IM65 Nail Gun how-to video.
