The Right Way to Change the Vibrator on a Belle PCLX 320 Plate Compactor
In this video, we show you how to change the Vibration Unit or Exciter on a Belle PCLX 320 Plate Compactor
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today we're going to change the vibrator unit on a Belle PCLX 320 Plate Compactor. Firstly, remove the cover by unscrewing the 4 bolts and washers using a 10mm socket. Then, remove the belt from the pulley and the clutch safely. Now, detach the bedplate by unscrewing the 4 bolts and washers using a 15mm socket. You will now need to release the exciter. To do this you will need to unfasten the 6 bolts using a 22mm socket. Remove the exciter. Place the new exciter back. A new exciter already contains oil, so this will not be needed. To secure the bolts back tightly, you will need to apply nut lock to each bolt. Place the bolt/s back and tighten loosely. Then secure with a 22mm socket, the fixture time of this nut lock is 5-8 mins. Reattach the bedplate and secure with the 4 bolts. Place the belt back into position. Return the cover back on and secure with the bolts That's how you change the vibrator unit on a Belle PCLX 320 Plate Compactor. If you have any issues, questions or would like to talk to our customer service team please visit our website. Please note L&S is a UK based trading company, please see our website for information on delivery to other countries.
Parts
Parts and tools included in the Belle PCLX 320 how-to video.
- Vibrator Unit - PCLX/VIB-01SP
- Bahco SL25 Socket Set of 25 Metric 1/4in Drive - BAHSL25
