Description
Autel EOBD Code Reader - Electrical & Battery Tester
Sealey part No. AL539B
- The Autel AL539B, an ultimate automotive analyser that combine a multimeter, scope, starter test and EOBD code reader.
- Starter test function allows testing of the battery and charging system.
- Fast and easy access to any vehicle’s EOBD diagnostic codes, establishing cause of illuminated engine check light (MIL).
- Features built-in data library with lookup functions.
- Clear, concise DTC generic definitions displayed on screen.
- CAN Enabled tool retrieves generic P0, P2 and P3 and U0 codes for engine emissions and manufacturer specific P1, P3 and U1 codes.
- Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze-frame data.
- Live display of O2 sensor data which can be stored and played back.
- Can be updated via web-based downloads and will link with a PC.
- Patented One-Click I/M Readiness button to eliminate drive cycle guesswork.
- Supports new extended sensor list (SAE J1979 2007), trouble-shooter code tips and repair information to identify root cause of the DTC, so saving time.
- Auto-ranging automotive diagnostic multimeter with volts, current and resistance.
- Scope function to visually test component signals, with the added benefit of maximum/minimum volts, frequency and duty cycle displayed.
- Includes battery clamps for non-load battery testing.
- Internal battery back-up for off-vehicle data review/analysis.
- Supplied with operating instructions, CD, USB cable and test leads in storage pouch.
Sealey part No. AL539B
- The Autel AL539B, an ultimate automotive analyser that combine a multimeter, scope, starter test and EOBD code reader.
- Starter test function allows testing of the battery and charging system.
- Fast and easy access to any vehicle’s EOBD diagnostic codes, establishing cause of illuminated engine check light (MIL).
- Features built-in data library with lookup functions.
- Clear, concise DTC generic definitions displayed on screen.
- CAN Enabled tool retrieves generic P0, P2 and P3 and U0 codes for engine emissions and manufacturer specific P1, P3 and U1 codes.
- Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze-frame data.
- Live display of O2 sensor data which can be stored and played back.
- Can be updated via web-based downloads and will link with a PC.
- Patented One-Click I/M Readiness button to eliminate drive cycle guesswork.
- Supports new extended sensor list (SAE J1979 2007), trouble-shooter code tips and repair information to identify root cause of the DTC, so saving time.
- Auto-ranging automotive diagnostic multimeter with volts, current and resistance.
- Scope function to visually test component signals, with the added benefit of maximum/minimum volts, frequency and duty cycle displayed.
- Includes battery clamps for non-load battery testing.
- Internal battery back-up for off-vehicle data review/analysis.
- Supplied with operating instructions, CD, USB cable and test leads in storage pouch.
Product Specifications
| L&S Part No. | SEAAL539B |
|---|---|
| Manufacturer | Sealey |
| OEM No. | AL539B |
| Unit of Sale | 1 |
| Size | Height: 250mm x Width: 290mm x Depth: 110mm |
